Our Products Details

LS1412H

The 16 m Scissor Lift (350 kg capacity) is designed for tasks that require maximum working height, stable lifting, and safe access to elevated areas. It is suitable for industrial, maintenance, and installation work where reaching higher levels is essential.

On many job sites, accessing high points safely becomes a challenge and can slow down work. This scissor lift provides a secure and stable platform with controlled lifting, helping complete tasks efficiently while reducing safety risks.

LS1412H

Key Features of LS1412H

Applications

Why Choose LS1412H

Why Choose BMR Equipment India Pvt. Ltd.?

Specifications

Working Height & Capacity

Max Working Height 16 m
Max Platform Height 13.7 m
Rated Load Capacity 350 kg

Dimensions

Platform Size (L × W) 2.28 × 1.35 m
Overall Length 3.1 m
Overall Width 1.38 m
Overall Height (Rails Down) 1.97 m
Min Platform Height 1.66 m

Performance

Drive Speed (Stowed) 4 km/h
Drive Speed (Raised) 0.7 km/h
Turning Radius (Inside/Outside) 0 / 2.65 m
Maximum Gradeability 25%

Battery & Power

Lift Motor 24V / 3.3 kW
Battery Capacity 24V / 270Ah
Charger 24V / 30A

Tires & Weight

Tire Size 381 × 127 mm (Solid, Non-marking)
Total Weight 3,700 kg
