LS1212H

The 14 m Scissor Lift (320 kg capacity) is designed for tasks that require extended reach, stable lifting, and safe access at height. It is suitable for maintenance, installation, and industrial work where higher working levels are involved.

On many job sites, reaching higher areas safely can slow down operations when using ladders or temporary setups. This scissor lift provides a secure platform with controlled lifting, helping complete work efficiently while maintaining safety standards.

LS1212H

Key Features of LS1212H

Applications

Why Choose LS1212H

Why Choose BMR Equipment India Pvt. Ltd.?

Specifications

Working Height & Capacity

Max Working Height 14 m
Max Platform Height 12 m
Rated Load Capacity 320 kg

Dimensions

Platform Size (L × W) 2.28 × 1.15 m
Overall Length 2.49 m
Overall Width 1.19 m
Overall Height (Rails Down) 2.07 m
Min Platform Height 1.48 m

Performance

Drive Speed (Stowed) 2 km/h
Drive Speed (Raised) 0.4 km/h
Turning Radius (Inside/Outside) 0.24 / 2.3 m
Maximum Gradeability 25%

Battery & Power

Lift Motor 24V / 3.3 kW
Battery Capacity 24V / 225Ah
Charger 24V / 30A

Tires & Weight

Tire Size 381 × 127 mm (Solid, Non-marking)
Total Weight 3,020 kg
