975E HD

The 975E HD Hydraulic Excavator is built for mining and large-scale earthmoving projects where maximum output, extreme digging force, and continuous performance are critical. It is suitable for operations that involve handling high volumes of material under demanding conditions.

On such sites, machines often face heavy stress, reduced efficiency, or increased downtime. The 975E HD is designed to manage these challenges with a high-power engine, strong hydraulic system, and robust structure, ensuring consistent productivity even in extreme working environments.

975E HD

Key Features of 975E HD

Applications

Why Choose 975E HD

Why Choose BMR Equipment India Pvt. Ltd.?

Specifications

General Specifications

Operating Weight 75,000 kg
Bucket Capacity (HD) 5.6 m³
Rated Power 524 hp @ 1,800 rpm

Performance

Arm Digging Force 630 | 375 kN
Bucket Digging Force 405 | 420 kN

Engine

Model Cummins QSM15 77C
Rated Power 524 hp @ 1,800 rpm
Peak Torque 2373 N.m @ 1,400 rpm

Dimensions

Shipping Length 12,630 mm
Shipping Width 4,260 mm
Shipping Height 4,710 mm
Track Shoe Width 650 mm

Hydraulic System

Maximum Flow 2 × 476 L/min
System Pressure 34.3 / 37.3 MPa
