Our Products Details

939E HD

The 939E HD Hydraulic Excavator is built for large-scale mining and heavy construction projects where maximum power, high digging force, and continuous performance are essential. It is designed for operations that require handling large volumes of material efficiently over long working hours.

On high-load sites, machines often face reduced efficiency, overheating, or frequent wear. The 939E HD is engineered to manage these challenges with high engine power, strong hydraulic flow, and a durable structure, ensuring stable performance even in demanding environments.

939E HD

Key Features of 939E HD

Applications

Why Choose 939E HD

Why Choose BMR Equipment India Pvt. Ltd.?

Specifications

General Specifications

Operating Weight 37,000 kg
Bucket Capacity 1.6 – 2.2 m³
Rated Power 340 hp @ 1,900 rpm

Performance

Arm Digging Force 243 kN
Bucket Digging Force 290 kN

Engine

Model Cummins L9PLUSE
Rated Power 340 hp @ 1,900 rpm
Peak Torque 1520 N.m @ 1,200 rpm

Dimensions

Shipping Length 11,350 mm
Shipping Width 3,190 mm
Shipping Height 3,175 mm
Track Shoe Width 600 mm

Hydraulic System

Maximum Flow 2 × 351 L/min
System Pressure 34.3 / 37.3 MPa
